Description
| Lens & Housing | |
|---|---|
| Lens Color | Clear |
| Lens Material | Hard-coated Polycarbonate |
| Housing Color | Gloss Black |
| Housing Material | Powder-coated Die-Cast Aluminum |
| Bezel Material | Electroplated, color-changeable & replaceable |
| Lighting | |
| Modes | Spot / Driving Beam with Amber DRL |
| Technology | LED |
| Projection Type | Forward Projection |
| Beam Pattern | Spot + Flood |
| Lighting Angle | 217° |
| Lighting Distance | 1 lux @ 677 yards (619 m) |
| Luminous Intensity (Center Beam) | Initial: 506,000 cd / Stable: 381,700 cd |
| Brightness (Lumen Output) | Low Beam: 10,169 lm (Initial) High Beam: 13,346 lm (Initial) |
| Color Temperature | High Beam: 6092K (Initial) Low Beam: 6168K (Initial) |
| Electrical | |
| Rated Voltage | 12V / 24V |
| Power Consumption | High Beam: 123W (Initial)(9.46 A(13V) Low Beam: 84.2W (Initial)(6.47 A(13V) |
| Light Sources | |
| Main LEDs | Spot: Luminus SFT-12R-WES-F (×4) + SST-40-WxS Flood: Luminus SFT-280FA-W-7545 (×3) |
| Side LEDs | Luminus SST-20F-W-AH (×6, 3 per side) |
| DRL LEDs | 2835 Chips, Amber |
| Performance | |
| 10m Lux (High Beam) | Initial: 5060 lux / Stable: 3817 lux |
| Lifespan | 50,000 hours |
| Waterproof Rating | IP68 / IP69K |
| Application | Universal |
| Mounting & Hardware | |
| Mounting Hardware Included | Yes |
| Material | Stainless Steel |
| Brackets | 2 × Gloss Black brackets with full set of M8, M6, M12 hex bolts (wrench included) |
| Wiring Harness | |
| Included | Yes |
| Connector | DT Plug, with mating connector |
| Length | 9.8 ft (3 m) |
| Material | Silicone Wire |
| Specs | Dual Output, 12 AWG main line, 12V/40A relay, 25A fuse, rocker switch with 3 × 22 AWG wires (3 m), insulated terminals, protective tubing |
| Package Contents | |
| • 2 × Lamp Bodies (Gunmetal front cover) • 2 × Black Bezels • 2 × Amber Bezels • 2 × Stainless Steel Brackets + full hardware • 1 × Dual-output Wiring Harness (3 m) • 1 × Inner Packaging with foam • 1 × Outer Packaging Box • 1 × User Manual • 2 x Pigtail wire |
|
