Oracle Lighting Titan 90W Off-Road Auxiliary Headlight – Pre-Order

Description

TITAN by ORACLE Lighting — a battle-tested 90W off-road auxiliary light engineered for extreme shock, vibration, and harsh environments with mission-ready White, Yellow, or IR output options.

90W Output10–32V Input60G Shock TestedIP69K WaterproofSpot / Flood Beam2-Year Warranty

Product Overview

Introducing the TITAN, the latest innovation from ORACLE Lighting and our toughest LED off-road light to date. Developed initially for military use, this isn’t just a light — it’s a battle-tested tool built to outperform and outlast.

Featuring a heavy-duty industrial bracket reinforced with an integrated anti-vibration shock plate, the TITAN stands unshaken in high-impact, high-speed environments. It’s tested to endure 60G shock forces and relentless vibration.

With a wide voltage input range (10V–32VDC) and full over/under voltage and reverse polarity protection, the TITAN ensures clean, stable power no matter where your rig takes you.

Available in White LED for maximum brightness, Yellow LED for fog-cutting clarity, and Infrared LED for night-vision operations — the TITAN adapts to your mission.

Certified for the real world with CE, RoHS, R10, and R112 compliance, designed for 50,000+ hours of operation, and backed by a 2-Year Warranty.

Key Features

• Heavy-duty industrial bracket design
• Optional anti-vibration shock plate
• Wide voltage input range: 10V–32VDC
• Over/under voltage & reverse polarity protection
• Certifications: CE, RoHS, R10, R112
• 50,000+ hours runtime
• Warranty: 2 Year

Specifications

• Beam Angle: Spotlight
• Input Voltage: 10V–32V
• Power Draw: 5A @ 12V / 2.5A @ 24V
• LED Chip: OSRAM
• Operating Power: 90W
• CCT Color Temp (White): 6000K
• Operating Temp: -40°F to 185°F
• RAW Lumens (6000K): 10,500 lm
• RAW Lumens (3400K): 9,700 lm
• Projection Distance: 640m
• Lux – Spot: (640m) 0.25 lx
• Lux – Flood: (240m) 0.25 lx
• Connector Type: Deutsch DT 2-Pin
• Lens Material: Polycarbonate
• Housing Material: Powdercoated Aluminum
• Mounting Hardware: 304 Stainless Steel
• Ingress Protection: IP69K Waterproof
• Lamp Dimensions: 120mm x 110mm x 86mm
• Lamp Weight: 3.7 lbs

Testing & Compliance

• Vibration: IEC 60068-2-6, 15.6Grms, 24—2000Hz
• Shock Test: IEC 60068-2-27, Grade: 2008, 60G
• EMC Test: CISPR 25 2008, Grade: R10 Class 4
• Ingress Protection: IEC60529, Grade: IP69K
• Certifications: CE, RoHS, R10, R112

Part Numbers & Options

5933-S-001Spot Beam / White LED5933-F-001Flood Beam / White LED5933-S-006Spot Beam / Yellow LED5933-F-006Flood Beam / Yellow LED5933-S-IRSpot Beam / IR LED5933-F-IRFlood Beam / IR LED

In the Box

• (1) 90W High Performance Auxiliary Light
